Extraction stirring mantles, EAMS 9602-03, 3 Position, 250ml, 450℃

Extraction stirring mantles, EAMS 9602-03, 3 Position, 250ml, 450℃

0.00৳

Heating mantles for extraction apparatus with stirring EAMS 9602-03, 250ml, 450℃

Heating mantles for extraction apparatus with stirrings EAMDS 9603-06, 250ml, 450℃

  • Extraction stirring mantles
  • 250ml, 3 & 6 place, 450℃, 150W×6
  • Model:EAMS 9602-03 & EAMDS 9603-06
  • Brand: Mtops
  • Origin: Korea

Description

Others models of products:

  • EAMDS 9601-03/EAMDS 9602-03/EAMDS 9603-03/EAMDS 9604-03
  • EAMDS 9601-06/EAMDS 9602-06/EAMDS 9603-06/EAMDS 9604-06
  • Construction with stirring and heating
  • Accurate temperature control by PID auto-tuning function
  • temperature : 450’C
  • Independent and Separate control function
  • Ideal for regulating experiment of the extraction, back flowing and distillation
  • Smooth start/stop
  • Ceramic fiber with strong thermal resistance
  • Stainless steel top cover with corrosion-proof
  • Maintain stirring speed accurately and uniformly by feedback control

Features

  • Extraction mantle has digital built-in PID controller with stirring.
  • Ideal for the experiment processes for repeated extraction, back flowing, distillation for the fields of foods, fiber, surroundings, petroleum, chemicals.
  • Consist of magnetic stirrer and heating mantle on one body, control temperature and stirring concurrently, control temperature and stirring independently
  • By use of the temperature controller with function of the built-in digital PID auto-tuning, control temperature accurately and confirm set temperature and actual temperature at the same time
  • Temperature controller with function of the built-in timer(99hr59min)
  • Maintain stirring speed accurately and uniformly by feedback control.
  • Smooth acceleration of stirring speed ensures no spillage.
  • Inner mantle part of the heating element consists of soft glass fiber, protected from damage of the flask and excellent contact between the heating element and flask and heating effectiveness is excellent.
  • Ceramic fiber with strong thermal-resistance has excellent thermal insulation and double housing design maintains low temperature of the mantle surface for user’s safety
  • With thermal resistance and durability bearing at the inner temperature over 450’C, strong metal housing  and powder coating with corrosion-proof.

※ External temperature sensor(Option) for the control of the sample temperature and the precise experiment.

※ Glassware is not included.

General Specifications

  • Heating Element Temperature: Up to 450℃ max
  • Temp. Controller : Digital PID auto-tuning
  • Timer : 99hr 59min
  • Temp. Accuracy : ±1℃ (on using external sensor)
  • Sensor probe : k Type
  • Speed Display : Scale
  • Speed control : Feedback control
  • Stirring speed : 100 ~ 1200 rpm
  • Thermal Insulation : Ceramic fiber
  • Material : Powder coated metal case
  • Top surface : Stainless steel
  • Support Rods : Ø 12.7mm dia.(standard)
  • Power Supply : 220V or 110V 50/60Hz

General Specification

Model Capacity Watts Number of
positions		 Dimensions
Ø× Height(mm)		 Internal
(height : mm)		 Weight (Kg)
EAMDS 9601-03 100ml 80W × 3 3 470×260×140 45 8.5
EAMDS 9602-03 250ml 150W × 3 3 520×280×150 60 9.7
EAMDS 9603-03 500ml 260W×3 3 580×300×165 75 10.2
EAMDS 9604-03 1000ml 380W×3 3 670×330×175 85 11.9
EAMDS 9601-06 100ml 80W×6 6 1040×280×150 45 16.6
EAMDS 9602-06 250ml 150W×6 6 1150×300×165 60 18.5
EAMDS 9603-06 500ml 260W×3 6 1340×330×175 75 19.9
EAMDS 9604-06 1000ml 380W×3 6 950×260×140 85 23

Warranty: 01 (One) year warranty from the date of installation.
