ST-LAB6 Automatic Cap Torque Tester, ESMC, Selectech/Terriss

0.00৳

ST-LAB6 Automatic Cap Torque Tester Price in Bangladesh

Brand: Selectech Terriss
Country of origin: Africa/USA

ST-LAB6 Automatic Cap Torque Tester in Bangladesh

Sure Torque’s ST-LAB series is the most automated closure Torque Tester on the market, with the ability to handle the most varied container and closure types.

The newest models of the ST-LAB family have user configurable automatic Top Load control for testing Child Resistant closures.

Main features of the new ST-LAB:

– FDA CFR 21 part 11 compliant logging
– Unlimited internal memory with full result logging (not possible to delete results)
– Batch-based memory structure. Results can be recalled in by: Year/Month/Day/Batch
– Programmable Top Load control
– Application angle measurement
– Fully automatic
– Quick testing (10-15 sec)
– Statistics on test type/sample type (average, sigma, cpk, in/under/over range)

The difference between the ST-LAB6 and the LAB5 is mainly the 21 CFR part 11 compliant logging and the memory capacity and structure. Main mechanical, control and change parts are the same by the LAB6 and the LAB5.

Application

Industries: Beverage, Food, Pharmaceutical, Packaging
Areas: Laboratory, Production

Applications:

Release torque testing without breaking seal integrity
Child Resistant closure testing with programmable Top Load
Automatic Application Angle measuring
Warranty ring application and breaking tests
Precision capping

Benefits

FDA CFR 21 part 11 compliant logging
Unlimited internal memory with full result logging (not possible to delete results)
Batch-based memory structure. Results can be recalled in by: Year/Month/Day/Batch
Release-application test without breaking the seal integrity of the product. This means: SAVING MONEY and ENVIRONMENT FRIENDLYNESS – the tested and re-torqued sample can be put back on the production line, instead of in the waste.
Automatic top load control enables the simple and accurate testing of the Child Resistant closures.
100% operator independent testing
All movements are fully automatic (not just the rotation, but also the container and closure gripping)
Quick testing – test speed can be set over a wide range
10 different test receipts for the different products
Many included test modes
Direct statistical analysis and report creating
Possibility to add custom test modes at any time (upgrade-file can be sent in email)

Additional Information

INCLUDED ACCESSORIES	1 set of change parts (container clamp and cap collet) Pc software and communication cables Calibration kit Foamed heavy duty transport case
SMARTPHONE REQUIREMENT	No
ANDROID VERSION	No
MEASURING RANGE	-8.5Nm – +8.5 Nm (cca +/- 75 lbfIn)
UNITS OF MEASUREMENT	LbfIn, LbfFt, Nm, dNm, Ncm, kgfcm
DISPLAYED VALUES	Actual, Max1, (Max2), torque-time graph
ACCURACY	+/- 0,2% F.S.
SAFE OVERLOAD	120%
MAXIMUM MEASURING FREQUENCY	80 Hz (12.5 ms)
RANGE ANALYSIS	Yes – In range / under range / over range
CAPABLE CLOSURE TYPES	any kind of twist cap
MAXIMUM SAMPLE SIZE	D200 x 375 mm
CALIBRATION KIT	included
OPERATION TIME	No
DC SUPPLY	DC 24V with included AD110/230 V adapter
BLUETOOTH RANGE	No
INCLUDED SOFTWARE	Data manager for PC
MEMORY	Unlimited – all te results of the life-cycle are stored
STORED DATA’S	Batch & measurement nr, peak results, date, time, graph, instrument serial number, comment, calibration date, BATCH code, IPC code
RESISTANCE GRADE	IP 54
LANGUAGE	English, German, Hungarian + custom language
DIMENSIONS: FOOTPRINT / HEIGHT	200x360x480 mm
NET WEIGHT	15 kg
SHIPPING PACKAGING	Heavy duty waterproof case as option
SHIPPING DIMENSIONS	56x47x27 cm
SHIPPING WEIGHT	depends on packing
COUNTRY OF MANUFACTURE	Hungary
WARRANTY	3 years
